ISO/IEC 10918-1 : 1993(E)
For progressive processes, a scan contains a partial encoding of all data units from one or more image components.
Components shall not be interleaved in progressive mode, except for the DC coefficients in the first scan for each
component of a progressive frame.
4.11
Summary of coding processes
Table 1 provides a summary of the essential characteristics of the various coding processes specified in this Specification.
The full specification of these processes is contained in Annexes F, G, H, and J.
Table 1 ­ Summary: Essential characteristics of coding processes
Baseline process (required for all DCT-based decoders)
·
DCT-based process
·
Source image: 8-bit samples within each component
·
Sequential
·
Huffman coding: 2 AC and 2 DC tables
·
Decoders shall process scans with 1, 2, 3, and 4 components
·
Interleaved and non-interleaved scans
Extended DCT-based processes
·
DCT-based process
·
Source image: 8-bit or 12-bit samples
·
Sequential or progressive
·
Huffman or arithmetic coding: 4 AC and 4 DC tables
·
Decoders shall process scans with 1, 2, 3, and 4 components
·
Interleaved and non-interleaved scans
Lossless processes
·
Predictive process (not DCT-based)
·
Source image: P-bit samples (2
P
16)
·
Sequential
·
Huffman or arithmetic coding: 4 DC tables
·
Decoders shall process scans with 1, 2, 3, and 4 components
·
Interleaved and non-interleaved scans
Hierarchical processes
·
Multiple frames (non-differential and differential)
·
Uses extended DCT-based or lossless processes
·
Decoders shall process scans with 1, 2, 3, and 4 components
·
Interleaved and non-interleaved scans
22
CCITT Rec. T.81 (1992 E)
