ISO/IEC 10918-1 : 1993(E)
K.3.3
Huffman table-specification examples
K.3.3.1
Specification of typical tables for DC difference coding
A set of typical tables for DC component coding is given in K.3.1. The specification of these tables is as follows:
For Table K.3 (for luminance DC coefficients), the 16 bytes which specify the list of code lengths for the table are
X'00
01
05
01
01
01
01
01
01
00
00
00
00
00
00
00'
The set of values following this list is
X'00
01
02
03
04
05
06
07
08
09
0A
0B'
For Table K.4 (for chrominance DC coefficients), the 16 bytes which specify the list of code lengths for the table are
X'00
03
01
01
01
01
01
01
01
01
01
00
00
00
00
00'
The set of values following this list is
X'00
01
02
03
04
05
06
07
08
09
0A
0B'
K.3.3.2
Specification of typical tables for AC coefficient coding
A set of typical tables for AC component coding is given in K.3.2. The specification of these tables is as follows:
For Table K.5 (for luminance AC coefficients), the 16 bytes which specify the list of code lengths for the table are
X'00
02
01
03
03
02
04
03
05
05
04
04
00
00
01
7D'
The set of values which follows this list is
X'01
02
03
00
04
11
05
12
21
31
41
06
13
51
61
07
X'
22
71
14
32
81
91
A1
08
23
42
B1
C1
15
52
D1
F0
X'
24
33
62
72
82
09
0A
16
17
18
19
1A
25
26
27
28
X'
29
2A
34
35
36
37
38
39
3A
43
44
45
46
47
48
49
X'
4A
53
54
55
56
57
58
59
5A
63
64
65
66
67
68
69
X'
6A
73
74
75
76
77
78
79
7A
83
84
85
86
87
88
89
X'
8A
92
93
94
95
96
97
98
99
9A
A2
A3
A4
A5
A6
A7
X'
A8
A9
AA
B2
B3
B4
B5
B6
B7
B8
B9
BA
C2
C3
C4
C5
X'
C6
C7
C8
C9
CA
D2
D3
D4
D5
D6
D7
D8
D9
DA
E1
E2
X'
E3
E4
E5
E6
E7
E8
E9
EA
F1
F2
F3
F4
F5
F6
F7
F8
X'
F9
FA'
158
CCITT Rec. T.81 (1992 E)
