For simplicity of implementation, the divide by 2 in the prediction selections 5 and 6 of Table H.1 is done by an

arithmetic-right-shift of the integer values.

The difference between the prediction value and the input is calculated modulo 2

16

. In the decoder the difference is

decoded and added, modulo 2

16

, to the prediction.

**H.1.2.2**

**Huffman coding of the modulo difference**

The Huffman coding procedures defined in Annex F for coding the DC coefficients are used to code the modulo 2

16

differences. The table for DC coding contained in Tables F.1 and F.6 is extended by one additional entry. No extra bits

are appended after SSSS

=

16 is encoded. See Table H.2.

**Table H.2 Difference categories for lossless Huffman coding**

SSSS

Difference values

1

0

0

1

1

1,1

1

2

3,2,2,3

1

3

7..4,4..7

1

4

15..8,8..15

1

5

31..16,16..31

1

6

63..32,32..63

1

7

127..64,64..127

1

8

255..128,128..255

1

9

511..256,256..511

10

1 023..512,512..1 023

11

2 047..1 024,1 024..2 047

12

4 095..2 048,2 048..4 095

13

8 191..4 096,4 096..8 191

14

16 383..8 192,8 192..16 383

15

32 767..16 384,16 384..32 767

16

32 768

**H.1.2.3**

**Arithmetic coding of the modulo difference**

The statistical model defined for the DC coefficient arithmetic coding model (see F.1.4.4.1) is generalized to a two-

dimensional form in which differences coded for the sample to the left and for the line above are used for conditioning.

**H.1.2.3.1**

**Two-dimensional statistical model**

The binary decisions are conditioned on the differences coded for the neighbouring samples immediately above and

immediately to the left from the same component. As in the coding of the DC coefficients, the differences are classified

into 5 categories: zero(0), small positive (

+

S), small negative (S), large positive (

+

L), and large negative (L). The two

independent difference categories combine to give 25 different conditioning states. Figure H.2 shows the two-dimensional

array of conditioning indices. For each of the 25 conditioning states probability estimates for four binary decisions are

kept.

At the beginning of the scan and each restart interval the conditioning derived from the line above is set to zero for the

first line of each component. At the start of each line, the difference to the left is set to zero for the purposes of calculating

the conditioning.
