JEITA CP-3451
- 125 -
Annex F
Notes on Conversion to Flashpix
The data recording method in this standard makes it possible to convert from Exif to Flashpix format with no loss of
image quality, and retaining all attribute information. A file that is thus designed from the start for conversion to
Flashpix is called a Flashpix-Ready (FPXR) file.
There are three main Flashpix-Ready functions:
g) All Exif tag information is mapped to the Flashpix Image Info Property Set,
h) APP2 extended data can be converted to Flashpix extensions,
i)
JPEG images can be converted to the Flashpix tile structure without image quality loss, making use of restart
markers.
Figure 53 illustrates the conversion process.
Figure 53 Conversion from Exif to Flashpix
Exif
SOI
APP1
(Exif data)
JPEG
Table
JPEG
Compressed
Data
(include Restart Marker)
APP2
(Contents List Data Area)
APP2
(Stream Data Area n)
APP2
(Stream Data Area 0)
DQT
DHT
DRI
SOF
SOS
EOI
Exif Tag
Information
to
Image info
Property
Set
FPXR
Application
Segment
to
FPX
Data
Stream
JPEG
to
Tiled JPEG
(Loss-less
Conversion)
Flashpix
Root
Property
Set
Object
Data res.0
Data res.1
Data res.n
Summary
Info.
CompObj
Stream
Info.
Extension
List
